product
FEATURES
1. High compatibility
2. Versatile functions
3. Efficient & stable
4. Easy to maintain
2. Versatile functions
3. Efficient & stable
4. Easy to maintain
PROCESS
Vibratory Bowl Feeding
↓
Cylinder gripper loading
↓
Automatic Winding
↓
Cylinder gripper unloading
↓
Cylinder gripper loading
↓
Automatic Winding
↓
Cylinder gripper unloading
SPECIFICATION
| Equipment model | TM-GM01 | TM-GM02 | TM-GM02T |
| Mode distinctions | Single-station | Dual-station | Dual-station (tape) |
| Voltage | Single-phase AC 220 | Single-phase AC 220 | Single-phase AC 220 |
| Power | 2.8KW | 3.3KW | 3.3KW |
| Atmospheric pressure | 0.4~ 0.6MPa | ||
| Wire diameter | 0.4~2.3mm | ||
| Length of the wire | <1200mm | ||
| Core OD | 12 ~ 40mm | ||
| Core ID | the inner hole must be large enough to allow a crochet hook to pass through | ||
| Production capacity | Related to the number of turns in the product's coil (0.8 1.5 seconds per lap) | ||
