PNEUMATIC SERVO TENSIONER
Used in various winding machine, motor winding machine, wire tensioners maintain the tension in wires to optimize their performance also can control tenioner when winding or wraping. Tensioners are typically adjustable, allowing fine-tune the tension level based on specific requirements. Some tensioners use springs or mechanical components to apply tension. The coil made by winding machine with tensioner, coil can use on relay,solenoid, transformer.
FEATURES
- Active wire feeding follow the speed of the winding machine
- Stable tension
- Suitable for medium quantity and different type
- Memory funtion
- It can use on relay, solenoid, transformer winding machine to good control
SPECIFICATION
| Wire Size | 0.05-0.14mm | 0.14-0.19mm | 0.12-0.45mm | 0.22-0.70mm |
| Tension Setting | Tension(cN) | Tension(cN) | Tension(cN) | Tension(cN) |
| 0.10% | 13 | 90 | ||
| 5.00% | 25 | 170 | ||
| 10.00% | 37 | 230 | 300 | |
| 15.00% | 49 | 280 | 400 | |
| 20.00% | 6 | 350 | 500 | |
| 25.00% | 73 | 430 | 600 | |
| 30.00% | 90 | 530 | 750 | |
| 40.00% | 105 | 650 | 1000 | |
| 50.00% | 120 | 130 | 790 | 1200 |
| 60.00% | 140 | 150 | 900 | 1400 |
| 70.00% | 170 | 1050 | 1700 | |
| 80.00% | 200 | 1200 | 1900 | |
| 90.00% | 220 | 1400 | 2100 | |
| 100.00% | 250 | 1500 | 2300 |
