Tags：
AUTO WINDING MACHINE
A coil winding machine is a device used to create coils that are used in various electronic applications. These machines are typically used in the manufacturing of relay, solenoid, transformers, inductors, and other electrical components. Teeming's winding machine can add cutter, twister, servo tensioner suit for your product. The coil winding machine controller is PAC controller, it can control the winding lineand connect with auto line to reduce cost and increase production capacity.
TM-1302_2 SPINDLE AUTO WINDING
Between 2 spindle pitch 130mm
TM-5004_4 SPINDLE AUTO WINDING
Between 2 spindle pitch 50mm
TM-8006_6 SPINDLE AUTO WINDING
Between 2 spindle pitch 80mm
TM-1006_6 SPINDLE AUTO WINDING
Between 2 spindle pitch 100mm
TM-5008_8 SPINDLE AUTO WINDING
Between 2 spindle pitch 50mm
TM-8008_8 SPINDLE AUTO WINDING
Between 2 spindle pitch 80mm
TM-1008_8 SPINDLE AUTO WINDING
Between 2 spindle pitch 100mm
TM-1308_8 SPINDLE AUTO WINDING
Between 2 spindle pitch 130mm
TM-3612_12 SPINDLE AUTO WINDING
Between 2 spindle pitch 36mm
TM-5012_12 SPINDLE AUTO WINDING
Between 2 spindle pitch 50mm
TM-8012_12 SPINDLE AUTO WINDING
Between 2 spindle pitch 80mm
TM-1012_12 SPINDLE AUTO WINDING
Between 2 spindle pitch 100mm
TM-3016_16 SPINDLE AUTO WINDING
Between 2 spindle pitch 30mm
TM-5016_16 SPINDLE AUTO WINDING
Between 2 spindle pitch 50mm
TM-5020_20 SPINDLE AUTO WINDING
Between 2 spindle pitch 50mm
TM-3624_24 SPINDLE AUTO WINDING
Between 2 spindle pitch 36mm
TM-3632_32 SPINDLE AUTO WINDING
Between 2 spindle pitch 36mm
TM-4032_32 SPINDLE AUTO WINDING
Between 2 spindle pitch 40mm
Q1: What is a coil winding machine?
A1: A coil winding machine is an automated or semi-automated device used to wind wire (typically copper or aluminum) evenly onto a core, bobbin, or frame. It is commonly used in the production of transformers, motors, inductors, solenoids, and other electronic or electromechanical components.
Q2: How to wind a wire coil?
A2: The wire coil winding process generally involves:
A1: A coil winding machine is an automated or semi-automated device used to wind wire (typically copper or aluminum) evenly onto a core, bobbin, or frame. It is commonly used in the production of transformers, motors, inductors, solenoids, and other electronic or electromechanical components.
Q2: How to wind a wire coil?
A2: The wire coil winding process generally involves:
- Setting winding parameters (number of turns, tension, speed, etc.)
- Loading the wire onto the tensioner
- Starting the machine to automatically wind the wire according to the preset direction and number of layers
- Completing the process with cutting, lead-out, soldering, or taping as needed
Q3: What is the cost of winding a coil?
A3: The cost depends on factors such as wire material, wire gauge, winding complexity, machine type, labor, and production volume. In general, automatic coil winding machines significantly reduce labor costs and improve yield, making them more cost-effective for medium- to high-volume production.
Q4: What types of wire can coil winding machines handle?
A4:Coil winding machines can process a wide variety of wires, including:
- Enamel-coated copper wire
- Insulated aluminum wire
- Multi-stranded wire
- Ultra-fine wire
- The supported wire types depend on the machine’s tension system and precision level.
Q5: How to maintain a coil winding machine?
A5: Regular maintenance includes:
- Cleaning machine components and moving parts
- Checking wire tensioners and wire guides
- Testing the responsiveness of the control system
- Lubricating and replacing wear parts (e.g., belts, linear rails)
- Routine maintenance ensures the machine’s stability and extends its lifespan.
