A BLDC motor winding machine is a device used to create motor that are used in various electronic applications. These machines are typically used in the manufacturing of motor.

Teeming's motor winding machine including cutter, also can option best tensioner for your product. The machine's controller is PAC controller, it can control the winding line and machine can connect with auto line.

Learn more: Decoding the Mechanics of BLDC Motor Winding Machines: Exploring Functionality, Key Features, and Advantages

Process - BLDC Motor Winding Machine

1. Load the bobbin onto the spindle of the BLDC motor winding machine. Secure the bobbin in place to prevent any movement during the winding process. The tooling serves as the foundation for the wire coils.


2.Start the BLDC motor winding machine to initiate the winding process. The machine will rotate the bobbin and guide the wire onto it according to the specified parameters.


3.End winding, once the desired number of turns or layers is reached, secure the ending end of the wire to the bobbin.


4.Carefully remove the fully wound bobbin from the spindle. Take care to avoid any damage to the wound coils during the unloading process.


Q1. What is a BLDC motor winding machine?

A1. A BLDC (Brushless Direct Current) motor winding machine is a specialized piece of equipment designed to automate the winding of coils for brushless DC motors.

Q2. What are the key advantages of using a BLDC motor winding machine?

A2. BLDC motor winding machines offer benefits such as increased winding precision, higher production efficiency, reduced labor costs, consistent winding quality, and the ability to handle various motor sizes and configurations.

Q3. How does a BLDC motor winding machine work?

A3. BLDC motor winding machines use automated processes to wind coils of wire onto stators or rotors, following precise winding patterns and tension control settings. These machines can be programmed to accommodate different motor specifications.
