A soldering machine is a specialized device used in electronics manufacturing and various other industries for the process of soldering.

The soldering machine is equipped with a heating element, the heating element rapidly heats the soldering tip to the desired temperature for melting the solder.

Soldering machines come with precise temperature control to ensure that the soldering tip reaches and maintains the optimal temperature for the specific soldering task. Different soldering applications require different temperatures to achieve the best results.

Soldering machines often have a digital display to show the set and actual temperatures, as well as control to adjust the temperature and other settings.
  1. Automatic 4 station
  2. Multi-station design
  3. Suitable for small quantity and different type of coil
  4. Customize jig and change it easy
  5. Automatic dip solder
  6. Can set volume of dip flux
  7. Automatic detect height of dip solder
  8. Function of displacement
  9. Dip cup up and down by servo motor
  10. Can set soldering time
  11. Promote effectiveness and increase capacity
Put coil to the fixture
Unload to conveyer

Learn more: What Is a Soldering Machine Used For?A Full Guide To Know How Does It Work!
Power source AC220V 1300W
Machine dimension 1000(L)x1000(W)x1300(H)mm
Weight  265KGS
Air pressure 5kgs/c㎡
Inner pot size 155(L)x105(W)x65(H)mm
Cycle time 1.5 sec/pcs
Pot Material Titanium
Temperature 600℃ Max.
Suitable products Transformer, relay, fan motor
Option 1.Solder cup up/down controlled by stepping or servo motor
2.Ohm Test
3.Wave solder
4.Flux density control
5.Tin feeder
6.Unload coil to belt
Due to machine improvement, machine specifications will be change without further notices.
